Technical Characteristics

Channels

2 electrical signal interfaces, one external sync interface

Sampling Rate

0.5M, 1M, 2.5M, 5M, 10M, 20Mselectable

Sampling Accuracy

12bit

Range Switching

60dB, 40dB, 20dB, 0dB, -20dBtotal 5 levels

Frequency Range

20k-100kHz, 80k-200kHz, 40k-300kHz

Range Non-Linearity Error

5%

Display

Display Screen

7” TFTtrue color touch LCDDisplay Screen

Resolution

800×480

Storage

Physical Storage

256MB  DDR2, operating memory

SDCard Storage

Standard 16G card, upgradeable to 32G, for storing test records and data

Interface

RS232

For synchronous transmission with PCInterface

USB

Can connect external mouse, keyboard, and external mobile storage devices

Power Supply Mode

Battery powered (16.8V Li-ion) + External Power Supply (18V) provides 8 hours of continuous operation

Electrical Signal Interface

2 channels BNC Interface(2 on front and rear panels each), for signal input

SMAInterface

External Sync Interface

SDCard Slot

Supports up to 32G SD card

Ethernet Port

Expandable

Ground Terminal

For external grounding

General Specifications

CPU

Clock Speed533MHz

System

WINCE6.0

Operating Temperature

-20℃to 45℃

Storage Temperature

-20℃to 60℃

Dimensions

L×W×H: 249mm × 216mm × 167mm

Weight

4.7kg
