Product Description
SXJS-IV Intelligent Dielectric Loss Tester
Darui Electric recommends： Dielectric Loss TesterTechnical Specifications 1. Ambient temperature: 0~40℃ (avoid prolonged sunlight on LCD) 2. Relative Humidity: 30%-70% 3. Power Supply: 220V±10%, 50±1Hz 4. Dimensions: 490x300x390mm 5. Weight: Approx. 18Kg 6. Output Power: 1KVA 7. Display Resolution: 4 digits 8. Measurement Range: Dielectric Loss TesterStructure SXJS-IV Intelligent D/L TesterIntegrated booster and measurement structure, output 2.5KV-10KV in 5 ranges, no external equipment needed.. Wiring similar to QSI bridge but more convenient. Fig.1: operation panel, Fig.2: wiring terminal diagram. (1) Display window - LCD screen. (2) Voltage selector - No HV output when set to "Off". (3) Keypad - Select mode, start, stop, print. (4) Power socket - Fuse: 5A. (5) Power switch - On/off. (6) Start light - HV output indicator. (7) Printer - Prints test results. Dielectric Loss Tester★★★★(8) Ground terminal - Must be reliably grounded before use!!! ★(9) Input IX: red (CX) to test object, black (E) HV reference, ground for normal, float for reverse. ★(10) Input IN - For external std capacitor only. IN must be <100mA!!! (11) HV output UH - Single clip lead (UH marked), to test object.
Note: The above information and technical parameters are compiled and published by Yangzhou Darui Electric Co., Ltd.
