Cable & Pipe Locator
Darui Electric recommends：

Cable & Pipe LocatorFeatures:

1. Patented omni-directional antenna design, 3D positioning.

2. Target pipe display shows direction and changes.

3. Guide arrow for quick target location.
4. Proximity signal strength display for accurate positioning.
5. Continuous depth display for efficiency.

6. Passive omni-directional mode for continuous power/radio signal search.
7. Custom frequency: 10Hz-35kHz manually settable.
8. Large, intuitive display.
9. Built-in passive frequency selection for finding unknown pipes.
10. Simple operation, portable.

Instrument Parameters

1. Transmitter

1) Output: 4 AC modes: low/medium/high/radio frequency, insulation impedance.

2) Power: constant output, 3 levels.

3) Modes: direct connection, coupling, induction.

4) Impedance display: 0-25000 ohms.

5) Load matching: auto adjustment.

6) Display: backlit, shows output energy, mode, self-test, load resistance.

7) Imported 18650 Li-ion battery, 500 cycles, >8h operation, battery indicator.

8) Dimensions: 277×227×153mm

9) Weight: 3.5kg

10) Operating: -10℃ to +45℃, RH 90%.

2. Receiver

Receiver has Basic and External modes. Only in A-frame mode can External mode be used.

Basic Reception Mode

    1) Frequency: low, medium, high, radio, 50Hz sinusoidal.

2) Modes: peak, null, depth measurement, current measurement.

3) Signal: digital size, bar length, sound intensity indicating signal strength.

4) Display: high-brightness LCD, sunlight readable, backlit for night use.

5) Gain: manual, dynamic range 000-100db.

6) Detection length: up to 15km direct connected.

Coupled: 3km per coupling, unlimited with multiple couplings.

Induction: 300m per induction, unlimited with multiple inductions.

7) Depth: direct read, range 000-300cm.

80% method depth measurement, range 000-300cm (coupling) 600cm (direct connection)

8) Current measurement: direct reading, range 000-999mA.

9) Accuracy: ±2.5%+5cm (0-2m)

10) Power: imported 18650 Li-ion, 500 cycles.

11) Standby: >12h, battery indicator.

12) Overheat/overcurrent: auto protection.

13) Operating Temp: -10C~40C.

14) Dimensions: 650×110×32mm

15) Weight: 1.6kg

Cable & Pipe Locatoris a fully automatic intelligent underground pipeline detector, featuring a powerful 8-antenna stereoscopic array that provides users with complete, accurate, and intuitive underground pipeline information. It can precisely locate and quickly trace underground pipelines. It is the world's only underground pipeline detector with target pipeline "imaging" display capability.


Note: The above information and technical parameters are compiled and published by Yangzhou Darui Electric Co., Ltd.
