JFD-2010 Dual-Channel Digital PD Detector

   JFD-2010 Dual-Channel Digital PD Detectorfeatures high sensitivity and wide test specimen applicability.It is a new-generation PD detector with Chinese characteristics reaching international advanced levels,Suitable for PD quantitative testing of motors, transformers, instrument transformers, cables, bushings, capacitors and other HV equipment。.

Structure:

1、 Independent dual-channel digital PD measurement，synchronous sampling, processing, display；

2、Internal/external sync freely selectable, with zero marking and phase resolution；

3、  Display mode: freely selectable ellipse, line, sine wave modes；

4、Single PD pulse waveform analysis to determine discharge characteristics；

5、Save test data/waveforms anytime, re-display and analyze previously saved records；

6、Gain Range: independent per-channel adjustment, waveform display smoothly adjustable without affecting results；

7、Single capture of special/random waveforms for detailed analysis；

8、Anti-static interference, removes phase-fixed interference signals；

Technical Specifications:

1.Testable capacitance range: :6pf~250uf.

2.Detection Sensitivity: :<0.02pc(Capacitance 50pF at).

3.Amplifier: ##bLow-end frequencyf1 10、20、30、50、80kHzselectable,##bHigh-end frequencyfh 100、200、300、400、500KHz selectable.Gain adjustment range>120db,inter-step gain difference20±1db.Positive/negative pulse response asymmetry<1db.

4.Time Window: width1°~360°,Window position freely rotatable.

5.Test Voltmeter: :0~200kV,digital display error<3%F.S.

6.Acquisition Channels: :4channels/card.

7.Input Impedance: :1MΩ.

8.Acquisition Card: zuiHigh Sampling Rate:20MHz.

9.ADResolution12BIT.DC Accuracy: 0.2%.

1O.Sample Length per Channel: :8M.

11.Trigger Mode: Manual, External Trigger, Internal Trigger.

12.Acquisition Card: Bandwidth: 3MHz(-##B).

13.Weight: approx. 15kg.


Note: The above information and Technical Parameters are compiled and published by Yangzhou Darui Electric Co., Ltd.
